Technical data:
* High and reliable operation performance
* Conventional panel series available for 2/4/8/16 detection zones
* Fully programmable using simple menu options
* Up to 25 devices for each zone including detector and manual call point
* Compatible with wide range of conventional devices
* Keypad entry to a wide range of engineering functions, including self-test, zone test, zone delay, non-lacking zone and evacuation over ride.
* LED indications available for short or open circuit of detection zone, sounder circuit and fire alarm outputs * One man walk-test and zone isolate facility
* Up to four programmable supervised sounder circuits
* Optional signal output board available for extension needs of fire and fault outputs
* Reserved repeater panel interface for fire alarm indication of multiple zones
* Three access levels settable via a key switch and an internal switch
* PCB’s produced using surface mount technology and microprocessor controller design
* Attractive surface mountable metal lid and enclosure
* Two wires system to reduce installation cabling and installer friendly
* LPCB approval in compliance with EN54-2 and EN54-4
